502501620 – Adjustable Beam High Bay

Part #: AHB-SEL-22000-8-50K-LVD
Model #: 502501620

Watts: 176.7
Lumens: 22,236
LPW: 126
CCT: 5000K
Input Voltage: 120-277V

SKU: 502501620 Category: Tags: , ,

Model #: 502501620
Part #
: AHB-SEL-22000-8-50K-LVD

ETi SSL’s Adjustable Beam High Bay Light is one of the most versatile high bay lights on the market! The advanced design has a leveraged function to customize the beam focus from a narrow angle beam at 60° to wide angle beam up to 120°. The Adjustable HB Series delivers 22,236 lumens of extremely uniform ambient 5000K illumination that is compatible with low-voltage dimmers (0-10V) for additional control flexibility. Installation is quick and easy with the included hook for suspension mounting at suggested mounting height of 25-35 feet.

The Adjustable Beam High Bay Light provides long-lasting maintenance free operation thanks to its reported 80.4% lumen maintenance @ 54,000 hours and projected L70 @ 87,000 hours. Fixture is rated to operate reliably from -40° C (-40° F) and in high ambient 45° C (113° F) applications. You can replace any outdated 400 watt HID high bay with this continuous, low-energy consumption light and decrease the monthly utility bill for your business!

Compatible Accessories:

70201102 – External Mount Step Dimming Microwave Occupancy Sensor
70205101 – OC Sensor Handheld Remote Programmer

SPECIFICATIONS

Weight 9.55 lbs
Dimensions 13.4 × 11.5 in
Wattage

176.7

Lumens

22,236

CRI

80

CCT (K)

5000K

Input Voltage

120-277

DLC

Standard
