MSFP | 2×2 Multi-Select Flat Panel with Lumen Boost® and Color Preference®

Part #: MSFP-22-LB3-8-CP3-MV-LVD

Order #: 64222501

KEY FEATURES
Each back-lit luminaire is ultra-thin with an overall height of 1.69” to fit shallow plenums and are IC rated for direct contact with insulation.

CCT & Light Quality
• 3 Selectable CCTs (3500K, 4000K, 5000K)
• 80+ CRI
Light Output & Efficacy
• 3 Selectable Wattages: 20W | 30W | 40W
• Efficacy Rating Range 2X4: 107 – 119
• 73% lumen maintenance @ 54,000 hours and projected L70 @ > 60,000 hours
Dimming, Voltage, Controls
• Universal voltage (120–277V, 50/60Hz)
• 0–10V dimming
• BBU Options Available

Available Accessories:
70343101 – 2X2 Multi-Select Flat Panel Surface Mount Kit (White)
70346101 – 2-Cable Suspension Mount Kit (max 3′)
